The minimum golf-simulator room is not one universal rectangle. Three envelopes overlap:
- the golfer's full swing,
- the screen or net's safe capture area,
- the launch monitor's tracking geometry.
Ignore any one of them and the build fails, even if the launch monitor technically powers on.
Evidence note: This is a source-led planning guide, not an installation report. Dimensions and placement rules were checked against official Garmin, Rapsodo, Voice Caddie, SkyTrak, and Uneekor sources on July 14, 2026. Always follow the current manual for the exact device and enclosure purchased.
Quick planning numbers
For an early go/no-go check:
- Ceiling height: 9 feet may work for some golfers; 10 feet is the safer planning target. SkyTrak says 10 feet typically offers ample clearance while many golfers report 9 feet is enough.
- Room width: 10 feet can support a centered single-handed setup; 12 feet is a better comfort target. Add width for both right- and left-handed players.
- Room depth with behind-ball radar: usually about 14–16 feet minimum from monitor to screen, before extra wall/enclosure clearance.
- Room depth with a side-mounted camera unit: the device no longer consumes 5–8 feet behind the ball, but the golfer, screen, projector, and safe ball flight still need room.
These are planning ranges, not permission to ignore a product manual.
Device-specific depth requirements
| Launch monitor | Device placement | Ball-to-screen/net | Total tracking depth | Source caveat |
|---|---|---|---|---|
| Garmin Approach R10 | 6–8 ft behind ball | At least 8 ft | At least 14–16 ft; Garmin requires a room at least 15 ft long | Room also at least 8 ft wide × 8 ft high |
| Rapsodo MLM2PRO | 6.5–8.5 ft behind ball | 8 ft | A little more than 14 ft per Rapsodo | Taller players may need the unit farther back for swing video |
| Voice Caddie SC4 Pro | About 5 ft behind ball | 10 ft recommended | About 15 ft | Unit must be level with the hitting surface |
| SkyTrak ST MAX | Beside ball | Defined by safe screen/enclosure setup | No 5–8 ft radar runway behind player | SkyTrak calls 17 ft comfortable overall, not a device minimum |
| Uneekor EYE MINI LITE | Beside ball; 12 in × 8 in hitting zone | 12 ft recommended; 10 ft minimum | Roughly ball-to-screen plus golfer clearance | Windows gaming PC and direct Ethernet are separate constraints |
Sources: Garmin placement requirements, Rapsodo product FAQ, Voice Caddie SC4 Pro setup, SkyTrak space guide, and Uneekor FAQ.
Height: the golfer decides before the enclosure
The launch monitor usually is not the height problem. The tallest golfer's driver swing is.
A 9-foot ceiling may work for a shorter golfer with a flatter swing. A tall golfer, upright swing, raised hitting platform, overhead door track, light fixture, or projector can make 10 feet feel tight.
Use this test before buying anything:
- Mark the intended ball position.
- Add the actual mat or platform height to the floor.
- Have every intended player make slow driver swings, then full-speed swings if safe.
- Check the club path against the ceiling, opener, tracks, lights, projector, and enclosure frame.
- Repeat from every ball position needed for right- and left-handed play.
A ceiling that “looks high enough” is not a measurement.
Width: centerline, handedness, and shanks
Width is not just screen width. It includes the golfer's body and club arc around the hitting position.
SkyTrak generally suggests 12 feet for a spacious setup and notes that both-handed play benefits from an additional 1–2 feet. An 8-foot-wide room can meet Garmin's published R10 minimum, but that does not guarantee comfortable driver swings for every golfer or enough side capture for poor strikes.
The centerline decision changes the room:
- Single-handed player: the ball can be offset to create more backswing clearance.
- Right- and left-handed players: a centered hitting position is easier, but needs more width.
- Floor camera unit beside the ball: may need to move when handedness changes.
- Centered behind-ball radar: stays on target line but consumes depth.
Depth: screen safety plus tracking runway
Depth contains several separate distances:
- screen or net clearance from the wall,
- ball flight from impact to screen,
- golfer and backswing space behind the ball,
- launch-monitor runway behind the ball for radar units,
- walking and seating clearance.
For R10, Garmin requires at least 8 feet from ball to net and 6–8 feet from ball to unit. For MLM2PRO, Rapsodo requires 8 feet to the net and 6.5–8.5 feet behind the ball. For SC4 Pro, Voice Caddie recommends 10 feet to the screen and about 5 feet behind.
Do not solve a depth shortage by shaving both sides of the vendor requirement. That can degrade tracking and move the golfer closer to a rebounding ball.
Radar interference and garage reality
Garmin's support guidance tells users to keep radar areas clear of large electronics and metal objects such as vehicles, refrigerators, fluorescent lights, fans, heaters, shiny surfaces, and structures that may affect performance.
A garage can contain all of those at once. Map these before choosing radar:
- parked vehicle,
- metal door and tracks,
- opener motor,
- refrigerator or freezer,
- HVAC equipment,
- fans and heaters,
- polished concrete,
- storage racks.
A side-mounted photometric unit may reduce radar runway problems, but it does not remove lighting, ball-placement, and protective-case requirements.
Projector geometry is its own system
The launch monitor can fit while the projector fails. Throw ratio, screen aspect ratio, image width, mount position, golfer shadows, and club clearance all interact.
Use the exact projector manufacturer's calculator or a model-specific throw calculator before drilling a mount. ProjectorCentral provides a model-based throw-distance calculator, but the projector manual remains the controlling source.
A short-throw projector can reduce shadows, but “short throw” is not one universal mounting distance.
A fail-closed measurement worksheet
Record these values in inches, not vibes:
- Floor to lowest obstruction: ______
- Clear room width at club height: ______
- Screen width and height: ______
- Screen/enclosure rear clearance: ______
- Ball to screen: ______
- Ball to launch monitor: ______
- Ball to rear wall/door: ______
- Tallest player's height: ______
- Right-handed, left-handed, or both: ______
- Mat/platform thickness: ______
- Projector model and throw ratio: ______
- Door-track/opener clearance: ______
Then compare each number to the current manuals for the launch monitor, enclosure, screen, mat, and projector.
Common mistakes
Buying the launch monitor before measuring
A sale price does not change the room. Measure first.
Treating “minimum” as “comfortable”
A minimum may let the device read a shot while leaving no room for safe movement, seating, or a tall golfer.
Forgetting the raised mat
A 2-inch platform removes 2 inches from ceiling clearance and changes the launch monitor's expected height relative to the ball.
Ignoring left-handed play
A bay that fits one handedness may put the other player's driver into a wall or force a floor camera to move.
Choosing projector placement last
The golfer, launch monitor, projector, and enclosure can all compete for the same ceiling or floor space.
Bottom line
- Plan on 9–10 feet of height, 10–12 feet of width, and 14–16 feet of tracking depth for a typical radar bay.
- Side-mounted camera units can reclaim the 5–8 feet behind the ball, but do not eliminate ball-to-screen, swing, or equipment clearance.
- Use vendor minimums as hard floors, not aspirational targets.
- Make full swings in the marked room before purchasing hardware.
Reality wins. The room does not care how good the launch monitor deal looked.
